分频输电系统静态电压稳定性分析
Analysis of Static Voltage Stability in Fractional Frequency Transmission Systems
【目的】 系统分析了分频输电系统（fractional frequency transmission system ，FFTS）的静态电压稳定性及功率极限特性，探究其在不同频率、拓扑结构下的变化规律与内在机理。【方法】 基于静态电压稳定性机理与连续潮流法，探索性发现FFTS的静态电压稳定性优势，以及不同拓扑下功率极限随频率下降呈现单调与非单调变化趋势，并基于戴维南等效电路推导有功功率极限表达式，揭示有功极限非单调变化致因。【结果】 相同拓扑下，FFTS静态电压稳定性优于工频运行；而有功功率极限随频率降低在某些拓扑中呈现“先增后减”的非单调特性，该现象源于PV节点相角与系统电抗的耦合效应，当耦合效应不影响功率极限时，功率极限单调变化。【结论】 FFTS的静态电压稳定性优势显著，但其功率极限受拓扑结构影响显著，需在系统设计中合理配置参数。
[Objective] This paper systematically analyzes the static voltage stability and power limit characteristics of the fractional frequency transmission system （FFTS）， exploring the variation laws and intrinsic mechanisms under varying frequencies and topological structures. [Methods] Based on the mechanism of static voltage stability and the continuation power flow method， the advantages of FFTS in static voltage stability are identified. The investigation reveals that the power limit shows both monotonic and non-monotonic trends as frequency decreases， depending on the network topology. Furthermore， the active power limit expression is derived based on the Thevenin equivalent circuit to elucidate the causes of non-monotonic variations. [Results] For a given topology， the static voltage stability of an FFTS is superior to that of the power system operating at power frequency. However， in specific topologies， the active power limit presents a non-monotonic characteristic of "increase-then-decrease" as frequency declines. This phenomenon originates from the coupling effect between the phase angle of the PV node and the system reactance. When this coupling effect does not affect the power limit， the power limit varies monotonically. [Conclusions] While FFTS offers significant advantages for static voltage stability， its power limits are highly sensitive to topological configurations. Consequently， system parameters must be carefully configured during the design phase.
分频输电系统 / 静态电压稳定性 / 连续潮流法 / 功率极限
fractional frequency transmission system / static voltage stability / continuation power flow method / power limit
