湿热型热浪下考虑生产特性的耦合工业集群用电管控方法
Power Consumption Management Method for Coupled Industrial Clusters Considering Production Characteristics Under Humid Heatwaves
【目的】热浪影响范围广、强度大,是对我国电力系统影响最大的气象灾害事件之一。工业用户用电体量大,且具备一定调节潜力,是参与电力保供的优质资源。现有研究未充分考虑湿热型热浪下温湿度耦合对温感负荷的影响,难以精准预测负荷缺口;传统用电管控未重视工业集群的产业链耦合特性,工程实践中常按统一比例切除负荷,易导致上下游企业被动停产、连锁断供,造成巨额经济损失。为此,提出一种湿热型热浪下考虑产业链耦合的工业集群用电管控方法。【方法】首先,结合温湿度等多种气象因素,生成高温场景下电力系统源荷序列,提升负荷缺口预测精度;其次,立足工业集群产业链耦合特性,建立考虑工业用户生产特性的内部负荷调控能力评估模型,并构建以最小化工业负荷计划调控损失及产业链耦合关联损失为目标的高工业负荷占比区域电网运行方式优化模型。最后,以我国东部某高工业负荷占比区域为实例开展仿真验证。【结果】与传统管控方法相比,所提方法可显著降低负荷调控损失及产业链连锁断供损失。【结论】所提方法能够有效应对湿热型热浪下工业集群用电管控的特殊挑战,弥补传统方法未考虑产业链耦合的缺陷,减少供需失衡下的综合损失,为电力系统迎峰度夏提供科学、可行的技术支撑。
[Objective] Heatwaves, featured by extensive influence and high intensity, are among the meteorological disaster events that exert the most significant impacts on China’s power system. Industrial consumers, possessing substantial power demand and considerable regulation potential, represent high-quality resources for ensuring a guaranteed power supply. However, existing studies have not fully accounted for the coupled effect of temperature and humidity on temperature-sensitive loads under humid heatwaves, which hinders the accurate prediction of load gaps. Furthermore, traditional power consumption control overlooks the industrial chain coupling characteristics inherent in industrial clusters. In engineering practice, loads are usually curtailed at a uniform proportion, which tends to trigger passive shutdowns of upstream and downstream enterprises and cascading supply disruptions, resulting in massive economic losses. To address these issues, this paper proposes a power consumption control method for industrial clusters considering industrial chain coupling under humid heatwaves.[Methods] First, by integrating multiple meteorological factors including temperature and humidity, the source-load sequence of the power system under high-temperature scenarios is generated to improve the accuracy of load gap forecasting. Second, based on the industrial chain coupling characteristics of industrial clusters, an evaluation model of internal load regulation capability is established, taking into account the production features of industrial consumers. Furthermore, an optimal operation model for regional power grids with a high proportion of industrial loads is constructed, with the objective of minimizing both the planned regulation loss of industrial loads and the coupled loss of the industrial chain.[Results] Simulation verification was conducted on a regional power grid with a high proportion of industrial loads in eastern China. The results demonstrate that the proposed method significantly reduces load regulation losses and cascading supply disruption losses within the industrial chain compared with traditional control methods.[Conclusions] The proposed method can effectively address the unique challenges of power consumption control for industrial clusters under humid heatwaves, remedy the deficiencies of traditional methods that ignore industrial chain coupling, and mitigate the comprehensive loss under supply-demand imbalance. This approach provides scientifically sound and feasible technical support for power systems managing peak summer loads.
湿热型热浪 / 工业集群 / 产业链耦合 / 供需平衡 / 有序用电
humid heatwave / industrial clusters / industrial chain coupling / supply-demand balance / orderly power consumption
| [1] |
Intergovernmental Panel on Climate Change. Climate change 2021-the physical science basis: working group I contribution to the sixth assessment report of the Intergovernmental Panel on Climate Change[M]. Cambridge, UK: Cambridge University Press, 2023.
|
| [2] |
张正华. “最艰难”的夏天,我们是怎么过来的?国网浙江电力迎峰度夏电力保供综述[N/OL]. 中国能源报. (2024-09-12). [2025-11-18]. https://www.cnenergynews.cn/dianwang/2024/09/12/detail_20240912176024.html.
|
| [3] |
需求侧响应有效助力四川迎峰度夏电力保供[EB/OL]. (2024-10-18) [2025-11-18]. https://www.nea.gov.cn/2024-10/18/c_1212405431.htm.
|
| [4] |
敖非, 余斌, 李祖坤, 等. 电压-负荷调节架构下的配电网灵活资源多时间尺度控制技术[J]. 湖南电力, 2025, 45(1): 112-120.
针对降压节能技术电压调整裕量有限、变频空调渗透率高且对电压变化灵敏度低的问题,提出一种电压-负荷调节构架下的配电网灵活资源多时间尺度控制技术。首先,对降压节能技术进行建模并分析其在配电网中的节能效益。其次,建立变频空调的负荷模型以评估其调控潜力。在此基础上,提出并制定一种配电网多时间尺度优化调控策略,在日前调度阶段,提前规划有载变压器(on load tap changer,OLTC)、空调负荷及分布式资源的调控方案,以减小配电网对上级电网的调峰压力,在日内优化阶段,针对可能出现的电压越限情况,实时调整OLTC挡位,并基于电气距离对配网中的柔性可调资源进行实时控制,以实现电网电压的快速恢复,增强系统的稳定性和鲁棒性。最后,基于IEEE 33节点系统进行案例分析,验证了所提策略的有效性。
Aiming at the problems of limited voltage adjustment margin, high penetration rate of variable frequency air conditioners and their low sensitivity to voltage changes for conservation voltage reduction(CVR) technology, a multi-time scale control technology for flexible resources in distribution networks within the framework of voltage-load regulation is proposed. Firstly, CVR is modeled and its energy-saving benefits in the distribution network are analyzed. Secondly, a load model for variable frequency air conditioners is established to assess its regulation and control potential. On this basis, a multi-time scale optimization control strategy for the distribution network is proposed and formulated. In the day-ahead scheduling phase, the regulation and control schemes for onload tap changers(OLTC), air conditioning loads, and distributed resources are planned in advance to reduce the peak regulation pressure of the distribution network on the upper grid. In the intra-day optimization phase, in response to potential voltage limit violations, the OLTC gear is adjusted in real time, and flexible and adjustable resources in the distribution network are controlled in real time based on electrical distance to realize rapid recovery of grid voltage, thereby enhancing the stability and robustness of the system. Finally, a case study based on the IEEE 33-node system is conducted to verify the effectiveness of the proposed strategy.
|
| [5] |
姜海洋, 蒋明华, 丁坤, 等. 极端静稳天气事件下电力系统风险评估与管控[J]. 电力系统自动化, 2025, 49(4): 42-52.
|
| [6] |
蔡先哲. 绿色技术创新影响工业绿色转型的机理与路径研究[D]. 大连: 大连海事大学, 2024.
|
| [7] |
李文琦, 孙伟卿, 杨文威. 考虑碳交易及需求响应的虚拟电厂运行优化策略[J]. 上海理工大学学报, 2024, 46(5): 484-493.
|
| [8] |
|
| [9] |
马薇. 树牢算账意识协同降低能耗[N]. 中国冶金报, 2025-05-22(6).
|
| [10] |
刘鹏龙, 王平欣, 夏晓东, 等. 考虑需求响应和碳交易的水泥企业生产调度方法研究[J]. 山东电力技术, 2025, 52(3): 12-20.
|
| [11] |
|
| [12] |
熊根鑫, 石文娟, 李淑贤, 等. 基于Holt-Winters法的配电台区售电量预测方法[J]. 信息技术, 2025(2): 180-186.
|
| [13] |
王安. 基于人工智能的电力系统负荷预测方法研究[N]. 中国工业报, 2025-06-23(13).
|
| [14] |
郭鑫溢, 姜凯, 杨朋威, 等. 基于深度强化学习的居民微电网调度算法[J]. 计算机与现代化, 2025(6): 106-113.
|
| [15] |
周聪, 李明, 袁隆发, 等. 基于联邦学习和DAL策略的电力负荷预测[J/OL]. 南京信息工程大学学报, 2025: 1-13. (2025-08-13) [2025-11-18]. https://doi.org/10.13878/j.cnki.jnuist.20250117001.
|
| [16] |
原野, 王海燕, 袁新平, 等. 基于可解释动态图注意力网络的短期电力负荷预测[J]. 计算机应用, 2025, 45(S1): 329-333.
|
| [17] |
朱俊澎, 李子钰, 李虎军, 等. 基于负荷分解与辨识的短期电力负荷预测[J]. 电力需求侧管理, 2025, 27(2): 55-61.
|
| [18] |
王翀, 高莉莎, 许梦晗. 基于纵向联邦回归的隐私保护电力负荷预测模型[J]. 电子器件, 2025, 48(1): 187-193.
|
| [19] |
曹晓庆, 李特, 李林, 等. 面向不平衡电网的改进型电压支撑方法研究[J]. 电力建设, 2025, 46(8): 34-44.
|
| [20] |
邱军, 孙力勇, 樊庆东. 一种基于三次样条插值的风电场出力预测评估方法[J]. 电气开关, 2023, 61(3): 16-18, 23.
|
| [21] |
甘磊, 杨天禹, 陈星莺, 等. 基于低碳工艺与流程控制的钢铁工业园区综合能源系统低碳调度方法[J]. 电网技术, 2023, 47(8): 3099-3110.
|
| [22] |
张路, 陈军, 南东亮, 等. 计及冶金负荷参与安全辅助服务的电网紧急负荷控制策略[J]. 电工电能新技术, 2023, 42(12): 77-87.
随着清洁能源装机容量不断增加,电力系统转动惯量呈下降趋势,使得系统在大扰动下的频率稳定问题更加严峻。为充分利用全网各种可控资源,本文提出了计及冶金负荷参与安全辅助服务的电网紧急负荷控制策略。首先,选取了典型冶金负荷——电解铝和炼钢作为主要控制对象,分析了两种负荷的用电特性。其次,以生产工艺环境要求作为限制条件,评估了两种冶金负荷可削减潜力。然后,构建了电网投资和用户侧需求响应收益的博弈模型,实现对冶金负荷参与安全辅助服务的合理补偿。最后,在IEEE 39节点系统中对所提策略进行验证,仿真结果表明:本文所提策略能迅速抑制频率下降,对冶金负荷的调用集中在低频减载前两轮,能够有效减少普通负荷切除量和用户的经济损失,为含高比例新能源送端系统的紧急频率控制提供了新方法。
As the installed capacity of clean energy continues to increase, the moment of inertia of the power system decreases, which makes the problem of frequency stability of the power system more serious under large disturbances. In this paper, in order to make full use of all kinds of controllable resources in the whole power grid, an emergency load control strategy of power grid considering metallurgical load participation in safety auxiliary service is proposed. First, the typical metallurgical loads-electrolytic aluminum and steel production-are selected as the main control objects, and the power consumption characteristics of the two loads are analyzed. Second, the reducible potential of the two metallurgical loads is evaluated with the requirement of the production process environment as the limiting condition. Then, the game theory model of power grid investment and consumer demand response earnings is constructed to achieve reasonable compensation for metallurgical load participation in safety auxiliary services. Finally, the proposed strategy is verified in the IEEE 39-bus system. Results of the case study show that: the proposed strategy can rapidly suppress the decrease in frequency; the reduction of metallurgical load is concentrated in the first two rounds of under frequency load shedding, which can effectively reduce the amount of ordinary load shedding and the economic loss of consumers. The proposed strategy provides a new method for emergency frequency control of power system with a large proportion of new energy.
|
| [23] |
涂夏哲, 徐箭, 廖思阳, 等. 考虑过程控制的钢铁工业负荷用能行为分析与功率特性建模[J]. 电力系统自动化, 2018, 42(2): 114-120.
|
| [24] |
于洪石, 杨世亮, 阳坤林, 等. 转炉吹炼水冷活动烟罩对烟气逸散控制机理的数值模拟[J]. 中国有色金属学报, 2024, 34(8): 2787-2800.
|
| [25] |
人力资源社会保障部办公厅关于做好高温天气劳动者权益保障工作的通知[EB/OL]. (2023-07-07)[2025-11-18]. https://www.gov.cn/zhengce/zhengceku/202307/content_6891693.htm.
|
| [26] |
孙诗洁, 叶承晋, 郭超, 等. 考虑工业用户生产特性的精细化用电管控模型及实证研究[J]. 电力科学与技术学报, 2023, 38(6): 44-54.
|
| [27] |
余传坤, 徐婷. 基于资源侧和需求侧的分布式光伏选址模型构建[J]. 地理空间信息, 2025, 23(9): 100-105.
|
| [28] |
刘耀先, 苏佳浩, 陈宋宋, 等. 产业负荷协同效应下基于GRDCC-BiGRU预测模型的行业负荷预测方法[J/OL]. 中国电机工程学报, 2025: 1-19. (2025-09-08)[2025-11-18]. https://link.cnki.net/urlid/11.2107.tm.20250908.1033.007.
|
| [29] |
宋晨曦. 虚拟电厂模式下园区综合能源服务运营优化研究[D]. 合肥: 中国科学技术大学, 2024.
|
| [30] |
李敏, 丁梦茹, 黄申茂, 等. 面向电网灵活性需求的纺织工业负荷柔性生产调度优化策略[J]. 电力系统自动化, 2025, 49(22): 156-169.
|
